D-2000

D-2000 850 k Visual Presenter, Document Camera
- Bright LED light for ideal illumination in darkened rooms.
- Suitable for microscope viewing.
- SD memory card slot for saving results etc.
- Flexible connectivity options using standerd interfaces.
- The fascination of moving pictures at 20 frames per second.
- Automatic brightness control for all lighting conditions.
- 5.2 X potical zoom with auto focus.
- Rugged design, sturdy casing.
- Easy to use - only 4 buttons, no PC required.
- A3 capture area for displaying e.g. maps, large books,
and experiments in one view. Camera Image pickup device 1/3“ CCD, 850.000 pixels
Effective pixels 1,024 (H) x 768 (V)
Frame rate 20 frames/ sec.
Resolution RGB out 600(H) x 600(V) TV Lines
Resolution Video out 400(H) TV Lines
Optics Zoom Powered (with double speed function ), 5.2x Optical
Lens F2.8 to 3.2, f=3.85 to 20.02mm
Shooting area Max 426 x 317mm
Aufnahmefeld Min 94 x 71mm
Focus Automatic / manual (powered)
Auto brightness controll Automatic / manual (powered)
Functions White balance Automatic / push set/ manual
Posi/Nega conversion Provided
Text mode Provided
Edge enhancement Provided (only in graphic mode)
Colour / Black & White selection Provided
Pause function Provided
Digital zoom Provided (8x)
Gamma adjustment Provided (only in graphic mode)
OSD – (on-screen display) Provided
Slide show Possible from SD Memory card
Image save Provided (SD Memory Card)
Image rotation Provided (0°, 180°)
Split Screen no
User Preset Up to 4 user settings
SyncSystem Internal
Movable Arm Provided
Provided
Microscope Viewing Mode Provided
Interface Internal selection Int./ RGB
Analog RGB out XGA (1,024x768 @60Hz)
Video out Composite
RGB in Provided
USB Provided
SD-Card slot Provided
Lighting Auxiliary lamp Provided
Others Measurements set up 350 x 370.5 x 411.5mm (W x B x H)
Measurements folded 195 x 254.5 x 444.5mm (W x B x H)
Weight 2,9 kg
Power consumption 9 W
Power source 12V DC (AC Adapter)
Accessories AC adapter, RGB cable, Instruction manual, removable stage, magnet sheet, anti-glare sheet, (A5 size), dust cover, USB cable, Image Mate, TWAIN DS driver
